48V 10A LiFePO4 LFP Lithium Battery Charger


Lithium Master

CRF-4810M

1 In Stock

Regular price $119.00
The 48V 10A LFP Battery Charger is a state of the art energy transfer device made and designed for Li-ion battery packs. This charger provides the required constant current, followed by constant voltage (CC/CV) charge profile for charging Li-ion batteries. This charger includes an LED display that changes from red to green...

The 48V 10A LFP Battery Charger is a state of the art energy transfer device made and designed for Li-ion battery packs. This charger provides the required constant current, followed by constant voltage (CC/CV) charge profile for charging Li-ion batteries. This charger includes an LED display that changes from red to green once the battery has reached full capacity.




Specifications



Model: CRF-04810M
Product Type: Metal Case
Battery Chemistry: Lithium Iron Phosphate - LiFePo4
Charging Connector: Alligator Clips
Input:
AC100-240V, 50/60HZ
Output:
58.4V 10A (CC/CV Charge Profile)
Capacity (Ah) of the charging battery: 40Ah or higher (recommended)
Weight: 2.8 lbs.  (1.25 kg)
Dimension Metric (L x W x H): 205 mm x 125 mm x 55 mm
Dimension Imperial (L x W x H): 8.3 in. x 4.9 in. x 2.2 in.
Normal Charge Current: 10.0 Amps
Charge Temperature: 0°C to 45°C
Storage Humidity: 60±25%R.H
Battery Protection Module*

Low Voltage Disconnect,
Over Voltage Disconnect,
Short Circuit Protection,
Reverse Polarity Protection,
Cell Balancing

  *Protections are integrated into Battery Pack BMS as standard

Policy

Warranty: 2 years standard Lithium-Ion Battery Warranty

Repair or Replace: first 2 years

Returns/exchange: 30 days

Cancellation: Within 24 Hours ⟶ No charge

Shipping: Standard within 2 business days
